- Brand: Dahua
- Model: VDP-DHI-KTP01-S
- Type: IP Villa Outdoor Station & Indoor Monitor
- IP Indoor Monitor
- Display: 7" TFT Screen
- Resolution: 1024 × 600
- Audio Input: 1 Channel All-direction Microphone
- Audio Output: Built-in 1.5W loudspeaker
- Audio Mode: Dual-way Bidirectional Talk
- Embedded Processor: Yes
- OS: Embedded Linux
- Storage: Micro SD, Maximum Capacity 32G, Standard Capacity 8G
- Audio Enhancement: Echo Cancellation/DNR
- DND Mode (Do Not Disturb): Yes
- Sub-station Quantity: 9
- Alarm Input: 6
- Alarm Output: 1
- Network: 1 RJ-45
- Power Supply Mode: PoE or DC 12V
- Power Consumption: Standby≤4W, work≤6W
- Dimensions: 119.6 × 221.5 × 21.5 mm
- IP Door Station
- Embedded Processor: Yes
- Storage: Extended 64G TF Card
- Camera: 1/2.8" 2MP CMOS High Definition Low Illumination Colorful
- Angle of View: H:160°, V:82°,D:180°
- Focal Length: 2 mm
- Noise Reduction: Noise Suppression and Echo Cancellation
- Frame Rate: PAL:25 fps NTSC:30 fps
- Audio Input: Built-in Omnidirectional Microphone
- Audio Mode: Built-in Loudspeaker
- Card Capacity: 10,000
- RS-485: 1
- Alarm Output/Input: 1/1
- Exit Button: 1
- Door Status Detection: 1
- Lock Control: 1
- Network Interface: 1
- Output Power: 12V/100mA
- Power Supply Mode: POE or DC 12V
- Power Consumption: ≤12W
- Dimensions: 130 ×96 ×28.5 mm
- Switch
- Interface: 4 × RJ-45 10/100M (PoE) - 1 × RJ-45 10/100M (uplink)
- Standard: IEEE802.3, IEEE802.3u, IEEE802.3x
- Switching Capacity: 1.8 Gbps
- Power Supply Voltage: 53V
- PoE Power Consumption: total ≤ 60 W
- Power Consumption: Idling: 0.8 W, Full load: 60 W
- Dimension: 130 × 85 × 26 mm
- Warranty: 2 Years with Warranty of the Authorized Agent
