- Brand: Dahua
- Model: DHI-KTP03
- Type: Villa Station & IP Indoor Monitor
-
IP Indoor Monitor
- Main Processor: Embedded Processor
- OS: Embedded Linux
- Display: 7" TFT Capacitive Touch Screen
- Resolution: 1024 × 600
- Audio Input: 1
- Audio Output: Built-in Speaker
- Audio Mode: 2-Way Voice Talk
- Audio Enhancement: Echo Suppression
- Storage: Micro SD Card, Max 64 GB
- DND Mode (Do Not Disturb): Yes
- Number of Extensions: Villa: 9 - Apartment: 4
- Alarm Input: 6
- Alarm Output: 1
- Network: 1x 10/100Mbps Ethernet Port
- Power Supply: 12 VDC 1A Standard PoE
- Power Consumption: ≤ 2 W (Standby), ≤ 6 W (Working)
- Operating Temperature: -10°C to +55°C
- Operating Humidity: 10%-95% (RH), Non-Condensing
- Dimensions: 189.6 x 134.6 x 26.0 mm
-
IP Door Station
- Main Processor: Embedded Processor
- OS: Embedded Linux OS
- Camera: 1/2.8" 2 MP CMOS High Definition, Low Illumination/DWDR/ Color/IR
- Angle of View: H: 107°, V: 61°, D: 122°
- Noise Reduction: 3D NR
- Video Compression: H.264; H.265
- Video Resolution: Main stream: 720p, WVGA, D1, CIF - Sub stream: 1080p, WVGA, D1, QVGA, CIF
- Frame Rate: PAL: 25 fps, NTSC: 30 fps
- Video Bit Rate: 256 Kbps-8Mbps
- Day/Night Mode: Auto(ICR)/Color/B/W;Color/B/W
-
Audio Input: 1
- Audio Output: Built-in Speaker
- Audio Mode: 2-Way Audio
- Audio Enhancement: Echo Suppression/Digital Noise Reduction
- Unlock Mode: Card, App, Indoor Monitor
- Card Capacity: 10,000
- RS-485: 1
- Exit Button: 1
- Door Status Detection: 1
- Lock Control: 1 Port, Normally Closed By Default
- Network: 1x 10/100Mbps Network Port (8-Core)
- Power Supply: 12 VDC 1A; Standard PoE
- Power Consumption: ≤ 1 W (Standby), ≤ 5 W (Working)
- Operating Temperature: -30 °C to +60 °C
- Operating Humidity: 10%-90%, Non-Condensing
- Protection: IP65
- Dimensions: 135.1 x 70.6 x 34.6 mm
-
Switch
- Main Processor: Embedded Processor
- Interface: 4x PoE Ports With 10/100Mbps Base-TX + 2x Uplink Ports With 10/100Mbps Base-TX
- Dimensions: 194.0 x 108.1 x 35.0 mm
- Warranty: 2 Years with Warranty of the Authorized Agent
