- Brand: EZVIZ
- Model: CS-EB3
- Type: Surveillance Camera
- Camera
- Image Sensor: 1/2.8” 3-Megapixel Progressive Scan CMOS Sensor
- Resolution: 2304 × 1296
-
Shutter Speed: Self-Adaptive Shutter
-
Lens Type: 2.8mm@ F2.0
-
Angle of View: 131° (Diagonal), 110° (Horizontal), 58° (Vertical)
-
Minimum Illumination: 0.01 Lux @(F2.0, AGC ON), 0 Lux with IR
- Day & Night: IR-Cut filter with auto-switching
-
DNR: 3D DNR
-
Night Vision: IR Distance:15m, Color Night Vision Distance:15m
- Network
-
Smart Alarm: Smart Human Motion Detection
-
Wi-Fi Pairing: AP Pairing
-
Protocol: EZVIZ Cloud Proprietary Protocol
-
General Function: Anti-Flicker, Heart Beat, Password Protection, Watermark
-
Minimum Network Requirements: 4Mbps
- Interface
-
Storage: Supports microSD Card (Up to 256 GB)
- Wi-Fi
-
Standard: IEEE802.11b, 802.11g, 802.11n
-
Frequency Range: 2.4 GHz ~ 2.4835 GHz
-
Channel Bandwidth: Supports 20MHz
-
Security: 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK
-
Transmission Rate: 11b: 11 Mbps, 11g: 54 Mbps, 11n: 72 Mbps
-
General
-
Operating Conditions: -20 °C to 50 °C (-4 °F to 122 °F ), humidity 95% or less (Non-condensing)
- IP Grade: Weatherproof Design
- Battery Capacity: 5200 mAh
-
Power Supply: DC 5V / 2A (Purchased Separately)
-
Power Consumption: Max. 10W
-
Dimensions: 105.9 × 62.8 × 62.8 mm
-
Weight: 522g
-
Warranty: 1 Year With Warranty Of The Authorized Agent
